Page 55
Chapter 3 Web Configurator Basics
NSA210 User’s Guide
55
3.6.3 Main Window
The main window
(
)
shows the screen you select in the navigation panel. It is
discussed in the rest of this document.
The Status screen is the first administration screen to display. See
for more information about the Status screen.
3.6.4 Status Messages
The message text box at the bottom of the screen
(
)
displays status messages
as you configure the NSA.
3.6.5 Common Screen Icons
The following table explains some icons that appear in several configuration
screens.
Maintenance
Power
Management
Configure power saving settings for the NSA and have
the NSA turn itself off and on or reboot according to the
schedules you configure.
Log
View the NSA’s logs and configure how you want to
receive the log reports.
Configuration
Back up and/or restore the NSA configuration file.
SSL
Configure HTTPS and the NSA’s SSL certificate.
FW Upgrade
Upload/upgrade new firmware to your NSA.
Shutdown
Restart the NSA or shut it down.
Logout
Click this to exit the web configurator. This is
recommended to prevent unauthorized administrator
access to the NSA.
Table 13 Screens Summary (continued)
LINK
SCREEN
FUNCTION
3
4
Table 14 Common Configuration Screen Icons
ICON
DESCRIPTION
Edit
Click this to go to a screen where you can change the configuration settings
of an entry.
Delete
Click this to delete an entry from the list.
Edit
Click this to jump to related item’s configuration screen.
