Prestige 310 Broadband Sharing Gateway
Remote Node Setup 5-7
Field Description Example
between 1 and 15. In practice, 2 or 3 is usually a good number.
Private This field is valid only for PPTP/PPPoE encapsulation. This
parameter determines if the Prestige will include the route to this
remote node in its RIP broadcasts. If set to Yes, this route is kept
private and not included in RIP broadcast. If No, the route to this
remote node will be propagated to other hosts through RIP
broadcasts. Yes
RIP Press the [SPACE BAR] to select the WAN RIP direction from Both/
None/In Only/Out Only. None
(default)
Version Press the [SPACE BAR] to select the RIP version from RIP-1/RIP-
2B/RIP-2M and None. RIP-1
Multicast Turn on/off IGMP support and select the version from IGMP-
v2/IGMP-v1/None. None
Once you have completed filling in the Network Layer Options Menu, press [Enter] to return to
Menu 11. Press [Enter] at the message [Press ENTER to Confirm...] to save your configuration, or
press [Esc] at any time to cancel.
5.2.1 Editing TCP/IP Options (with PPTP Encapsulation)
Make sure that Encapsulation is set to PPTP in Menu 11.1. Then move the cursor to the Edit IP field in
Menu 11.1, press the [SPACE BAR] to toggle No to Yes. Press [Enter]
to open Menu 11.3 - Network
Layer Options.
Figure 5-5 Remote Node Network Layer Options
The next table gives you instructions about configuring remote node network layer options.
Menu 11.3 - Remote Node Network Layer Options
IP Address Assignment= Dynamic
Rem IP Address= N/A
Rem Subnet Mask= N/A
My WAN Addr= 0.0.0.0
Single User Account= Yes
Metric= 1
Private= No
RIP Direction= None
Version= N/A
Multicast= None
Enter here to CONFIRM or ESC to CANCEL:
Press Space Bar to Toggle.
