Prestige 310 Broadband Sharing Gateway
Internet Access 3-8
subnetting, use the subnet mask computed by the Prestige
RIP Direction Press the space bar to select the RIP direction from None, Both/In
Only/Out Only. None
Version Press the space bar to select the RIP version from RIP-1/RIP-
2B/RIP-2M. RIP-1
Incoming
Protocol Filters Enter the filter set(s) you wish to apply to the incoming traffic
between this node and the Prestige.
Outgoing
Protocol Filters Enter the filter set(s) you wish to apply to the outgoing traffic between
this node and the Prestige.
When you have completed this menu, press [Enter] at the prompt [Press ENTER to Confirm…] to save
your configuration, or press [Esc] at any time to cancel.
3.3 Internet Access Setup
You will see three different Menu 4 screens depending on whether you chose Ethernet, PPTP or PPPoE
Encapsulation.
3.3.1 Ethernet Encapsulation
Step 1. You must choose the Ethernet option when the WAN port is used as a regular Ethernet. The
PPPoE choice is for a dial-up connection using PPPoE. If you choose Ethernet in Menu 4 you will see the
next screen.
Figure 3-6 Internet Access Setup (Ethernet)
Menu 4 - Internet Access Setup
ISP's Name= ChangeMe
Encapsulation= Ethernet
Service Type= Standard
My Login= N/A
My Password= N/A
Login Server IP= N/A
IP Address Assignment= Dynamic
IP Address= N/A
IP Subnet Mask= N/A
Gateway IP Address= N/A
Single User Account= Yes
Press ENTER to Confirm or ESC to Cancel:
