Chapter 9 vlanQoS Commands
P-870MH-C1 User’s Guide
60
Use this command to save the current settings for port-based VLAN, IEEE 802.1Q VLAN,
and QoS to non-volatile memory in the P-870MH-C1. Otherwise, these settings are lost when
the P-870MH-C1 reboots or restarts.
9.9 vlanQoS Command Examples
This section shows two VLAN configuration examples.
9.9.1 Port-based VLAN
Commands:
vlanQoS modechane <0|1>
vlanQoS pvlanset
vlanQoS clear
The P-870MH-C1 always uses either port-based VLAN or IEEE 802.1Q VLAN. In either
case, the default settings make the P-870MH-C1 behave like a regular switch.
Use port-based VLAN to create groups of ports that broadcast traffic to each other. For
example, if you combine ports 1, 2, and 5 (DSL), then incoming traffic on any of these ports is
broadcast to the other ports. They do not broadcast traffic to ports 3 and 4, and ports 3 and 4 do
not send traffic to ports 1, 2, or 5. If you then combine ports 3, 4, and 5, incoming traffic from
port 5 is broadcast to ports 1-4 because it is part of both groups. Incoming traffic from ports 3
and 4 is only broadcast to ports 3-5.
Use the vlanQoS save command to save your changes to non-volatile memory.
Examples:
Figure 38 Enable Port-based VLAN (Disable IEEE 802.1Q VLAN)
Figure 39 Look at the Current Settings for Port-based VLAN
ras> vlanQoS mode 0
ras> vlanQoS save
ras> vlanQoS mode 0
ras> vlanQoS disp
