Chapter 2 Introducing the SMT
P-870MH-C1 User’s Guide
24
2.1.3 SMT Menus Overview
The following table gives you an overview of your P-870MH-C1’s various SMT menus.
2.2 Navigating the SMT Interface
The SMT (System Management Terminal) is the preferred interface that you use to configure
your P-870MH-C1.
Several operations that you should be familiar with before you attempt to modify the
configuration are listed in the table below.
Table 2 SMT Menus Overview
MENUS SUB MENUS
1 General Setup 1.1 Configure Dynamic DNS
3 LAN Setup 3.2 TCP/IP and DHCP Setup 3.2.1 IP Alias Setup
23 System Password
24 System Maintenance 24.1 Status
24.2 System Information and
Console Port Speed
24.2.1 Information
24.2.2 Change Console Port Speed
24.3 Log and Trace 24.3.1 View Error Log
24.3.2 UNIX Syslog
24.7 Upload Firmware 24.7.1 Upload System Firmware
24.7.2 Upload System Configuration File
24.8 Command Interpreter Mode
Table 3 Navigating the SMT Interface
OPERATION KEY STROKE DESCRIPTION
Move down to
another menu
[ENTER] To move forward to a submenu, type in the number of the
desired submenu and press [ENTER].
Move up to a
previous menu
[ESC] Press [ESC] to move back to the previous menu.
Move to a hidden
menu
Press [SPACE
BAR] to change
No to Yes then
press [ENTER].
Fields beginning with "Edit" lead to hidden menus and have a
default setting of No. Press [SPACE BAR] once to change No to
Yes, then press [ENTER] to go to the "hidden" menu.
Move the cursor [ENTER] or [UP]/
[DOWN] arrow
keys.
Within a menu, press [ENTER] to move to the next field. You
can also use the [UP]/[DOWN] arrow keys to move to the
previous and the next field, respectively.
Entering
information
Type in or press
[SPACE BAR],
then press
[ENTER].
You need to fill in two types of fields. The first requires you to
type in the appropriate information. The second allows you to
cycle through the available choices by pressing [SPACE BAR].
Required fields or
ChangeMe
All fields with the symbol must be filled in order to be able
to save the new configuration.
All fields with ChangeMe must not be left blank in order to be
able to save the new configuration.
N/A fields Some of the fields in the SMT will show a . This symbol
refers to an option that is Not Applicable.
