Chapter 3 Configuration Using the SMT
P-870MH-C1 User’s Guide
28
Fill in the required fields. Refer to the table shown next for more information about these
fields.
3.3 LAN Setup
This section describes how to configure the Ethernet using Menu 3.2 — TCP/IP and DHCP
Ethernet Setup.
To edit Menu 3.2, enter 3 from the main menu to display Menu 3 — LAN Setup. When Menu
3 appears, press 2 and press [ENTER] to display Menu 3.2 — TCP/IP and DHCP Ethernet
Setup as shown next
.
Figure 7 Menu 3.2 TCP/IP and DHCP Ethernet Setup
The following table describes the fields in this screen.
Table 5 Menu 1 General Setup
FIELD DESCRIPTION
System Name Choose a descriptive name for identification purposes. This name can be up to
30 alphanumeric characters long. Spaces are not allowed, but dashes “-” and
underscores "_" are accepted.
Domain Name Enter the domain name (if you know it) here. If you leave this field blank, the ISP
may assign a domain name via DHCP. You can go to Menu 24.8 and type "sys
domainname" to see the current domain name used by your gateway.
If you want to clear this field just press the [SPACE BAR]. The domain name
entered by you is given priority over the ISP assigned domain name.
When you have completed this menu, press [ENTER] at the prompt “ Press ENTER to Confirm
or ESC to Cancel: ” to save your configuration, or press [ESC] at any time to cancel.
Menu 3.2 - TCP/IP and DHCP Ethernet Setup
DHCP= None TCP/IP Setup:
Client IP Pool:
Starting Address= N/A IP Address= 192.168.1.2
Size of Client IP Pool= N/A IP Subnet Mask= 255.255.255.0
Multicast= None
Edit IP Alias= No
Press ENTER to Confirm or ESC to Cancel:
Table 6 Menu 3.2 TCP/IP and DHCP Ethernet Setup
FIELD DESCRIPTION
DHCP If set to Server, your P-870MH-C1 can assign IP addresses, a default
gateway and DNS servers to a compuer(s) set to use a dynamic IP address.
(DHCP client).
If set to None, the DHCP server will be disabled.
When DHCP server is used, the following items need to be set:
Client IP Pool
