Chapter 3 Configuration Using the SMT
P-870MH-C1 User’s Guide
30
Figure 9 Menu 3.2.1 IP Alias Setup
Follow the instructions in the following table to configure IP Alias parameters.
3.4 System Maintenance
This section covers the information and diagnostic tools in SMT menus 24.1 to 24.7.
These tools include updates on system status, port status, log and trace capabilities and
upgrades for the device firmware and configuration.
Type 24 in the main menu to open Menu 24 – System Maintenance, as shown in the
following figure.
Menu 3.2.1 - IP Alias Setup
IP Alias 1= No
IP Address= N/A
IP Subnet Mask= N/A
RIP Direction= N/A
Version= N/A
Incoming protocol filters= N/A
Outgoing protocol filters= N/A
IP Alias 2= No
IP Address= N/A
IP Subnet Mask= N/A
RIP Direction= N/A
Version= N/A
Incoming protocol filters= N/A
Outgoing protocol filters= N/A
Enter here to CONFIRM or ESC to CANCEL:
Table 7 Menu 3.2.1 IP Alias Setup
FIELD DESCRIPTION
IP Alias Choose Yes to configure the LAN network for the P-870MH-C1.
IP Address Enter the IP address of your P-870MH-C1 in dotted decimal notation
IP Subnet Mask Your P-870MH-C1 will automatically calculate the subnet mask based on the IP
address that you assign. Unless you are implementing subnetting, use the subnet
mask computed by the P-870MH-C1
RIP Direction Press [ SPACE BAR ] to select the RIP direction. Choices are None, Both, In Only
or Out Only.
Version Press [ SPACE BAR] to select the RIP version. Choices are RIP-1, RIP-2B or RIP-
2M.
Incoming
Protocol Filters
Enter the filter set(s) you wish to apply to the incoming traffic between this node and
the P-870MH-C1.
Outgoing
Protocol Filters
Enter the filter set(s) you wish to apply to the outgoing traffic between this node and
the P-870MH-C1.
When you have completed this menu, press [ENTER] at the prompt “ Press ENTER to Confirm
or ESC to Cancel: ” to save your configuration, or press [ESC] at any time to cancel.
