Chapter 3 Configuration Using the SMT
P-870MH-C1 User’s Guide
31
Figure 10 Menu 24 System Maintenance
3.4.1 System Status
The first selection, System Status, gives you information on the status and statistics of the
ports, as shown next. System Status is a tool that can be used to monitor your P-870MH-C1.
Specifically, it gives you information on your line status, number of packets sent and received.
To get to System Status, type 24 to go to Menu 24 — System Maintenance. From this menu,
type 1.
Figure 11 Menu 24.1 System Maintenance : Status
The following table describes the fields in this menu. .
Menu 24 - System Maintenance
1. System Status
2. System Information and Console Port Speed
3. Log and Trace
7. Upload Firmware
8. Command Interpreter Mode
Enter Menu Selection Number:
Menu 24.1 - System Maintenance - Status
Port Status TxPkts RxPkts Cols Tx B/s Rx B/s Up Time
LAN 100M/Full 289 5582 0 214 256 0:33:55
VDSL HANDSHAKE 0 0 0 0 0 0:00:00
Port Ethernet Address IP Address IP Mask DHCP
LAN 00:13:49:BB:94:AC 192.168.1.2 255.255.255.0 None
System up Time: 0:34:00
Press Command:
COMMANDS: 1-Reset Counters ESC-Exit
Table 8 Menu 24.1 System Maintenance: Status
FIELD DESCRIPTION
Port This field displays the type of the port (LAN or VDSL).
Status This shows the status of the remote node.
TxPkts The number of transmitted packets to this remote node.
RxPkts The number of received packets from this remote node.
Cols This is the number of collisions.
Tx B/s This shows the transmission rate in bytes per second.
