Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. YZB06012
INDOOR COIL MODEL NO. FC/MC62D
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
1650 1900 2150
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 71.5 4.9 4.3 72.1 4.8 4.4 72.7 4.6 4.6
70 70.3 5.4 3.8 70.9 5.3 3.9 71.5 5.1 4.1
80 69.2 5.9 3.4 69.8 5.8 3.5 70.3 5.6 3.7
47
60 61.1 4.8 3.8 61.2 4.7 3.8 61.4 4.6 3.9
70 60.3 5.3 3.4 60.6 5.2 3.4 60.8 5.1 3.5
80 59.6 5.8 3.0 59.9 5.7 3.1 60.2 5.6 3.2
40
60 53.5 4.7 3.3 50.2 4.6 3.2 47.0 4.6 3.0
70 53.7 5.3 3.0 52.0 5.1 3.0 50.4 5.0 3.0
80 53.9 5.9 2.7 53.8 5.6 2.8 53.8 5.4 2.9
30
60 43.9 4.6 2.8 42.5 4.5 2.8 41.1 4.5 2.7
70 44.0 5.2 2.5 42.6 5.1 2.4 41.1 5.1 2.4
80 44.2 5.8 2.2 42.7 5.7 2.2 41.2 5.6 2.1
17
60 35.4 4.4 2.4 35.0 4.3 2.4 34.6 4.3 2.4
70 35.0 4.9 2.1 35.3 4.9 2.1 35.7 4.8 2.2
80 34.5 5.4 1.9 35.7 5.4 1.9 36.8 5.4 2.0
10
60 30.7 4.4 2.1 28.9 4.3 2.0 27.2 4.3 1.9
70 30.9 4.9 1.8 30.0 4.9 1.8 29.1 4.9 1.8
80 31.1 5.5 1.7 31.0 5.4 1.7 31.0 5.4 1.7
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil MBH KW COP
MV20D FC/MC62D 1.00 1.01 0.99
MA20D FC/MC62D 1.00 1.00 1.00
Variable Speed
Furnace
Coil MBH KW COP
P(C,V)9*D20 FC/MC62D 0.96 1.01 0.99
Y*(8,L)C*C20 FC/MC62D 0.98 1.00 0.98
Y*9C*C20 FC/MC62D 0.99 0.99 1.00
Y*9C*D20 FC/MC62D 0.99 0.99 1.00
G*9V*C20 FC/MC62D 0.99 0.99 1.00
G*9V*D20 FC/MC62D 0.99 0.99 1.00
