York YZB018 THRU 060 - Manual (Page 31)

271457-YTG-B-0908
Johnson Controls Unitary Products 31
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. YZB06012
INDOOR COIL MODEL NO. FC/MC62D
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1650 1900 2150
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 57 57 62 62 67 72
65
T.C. 54.0 56.6 57.2 62.9 69.4 55.2 57.9 58.6 63.7 70.3 56.3 59.3 59.9 64.5 71.3
S.C. 54.0 56.6 57.2 62.9 69.4 55.2 57.9 58.6 63.7 70.3 56.3 59.3 59.9 64.5 71.3
K.W. 3.4 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.6 3.6 3.6 3.6 3.6 3.6
75
T.C. 52.4 54.5 54.8 60.2 66.5 53.7 55.7 56.0 61.1 67.3 55.0 56.9 57.3 61.9 68.2
S.C. 52.4 54.5 54.8 60.2 66.5 53.7 55.7 56.0 61.1 67.3 55.0 56.9 57.3 61.9 68.2
K.W. 3.9 3.9 3.9 3.9 3.9 3.9 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.1 4.1
85
T.C. 50.7 52.5 52.4 57.5 63.5 52.2 53.5 53.5 58.4 64.3 53.6 54.6 54.6 59.4 65.1
S.C. 50.7 52.5 52.4 57.5 63.5 52.2 53.5 53.5 58.4 64.3 53.6 54.6 54.6 59.4 65.1
K.W. 4.3 4.3 4.3 4.3 4.3 4.4 4.4 4.4 4.4 4.4 4.5 4.5 4.5 4.5 4.5
95
T.C. 49.1 50.5 49.9 54.8 60.6 50.7 51.3 50.9 55.8 61.3 52.3 52.2 51.9 56.8 62.0
S.C. 49.1 50.5 49.9 54.8 60.6 50.7 51.3 50.9 55.8 61.3 52.3 52.2 51.9 56.8 62.0
K.W. 4.7 4.7 4.7 4.7 4.8 4.8 4.8 4.8 4.8 4.9 4.9 4.9 4.9 4.9 4.9
105
T.C. 46.5 47.0 47.0 51.2 56.7 47.8 48.0 47.8 52.0 57.4 49.2 49.0 48.5 52.9 58.0
S.C. 46.5 47.0 47.0 51.2 56.7 47.8 48.0 47.8 52.0 57.4 49.2 49.0 48.5 52.9 58.0
K.W. 5.2 5.3 5.2 5.3 5.3 5.3 5.3 5.3 5.4 5.4 5.4 5.4 5.4 5.5 5.5
115
T.C. 44.0 43.6 44.2 47.6 52.9 45.1 44.7 44.7 48.4 53.5 46.1 45.8 45.2 49.2 54.2
S.C. 44.0 43.6 44.2 47.6 52.9 45.1 44.7 44.7 48.4 53.5 46.1 45.8 45.2 49.2 54.2
K.W. 5.8 5.8 5.8 5.8 5.9 5.9 5.9 5.9 5.9 5.9 6.0 5.9 6.0 6.0 6.0
125
T.C. 41.4 40.3 41.4 44.1 49.1 42.3 41.4 41.6 44.7 49.7 43.1 42.6 41.9 45.4 50.3
S.C. 41.4 40.3 41.4 44.1 49.1 42.3 41.4 41.6 44.7 49.7 43.1 42.6 41.9 45.4 50.3
K.W. 6.3 6.4 6.3 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.5 6.5 6.5 6.5 6.5
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
MV20D FC/MC62D 1.00 1.01 1.00
MA20D FC/MC62D 1.00 1.00 1.00
Variable Speed
Furnace
Coil T.C. S.C. KW
P(C,V)9*D20 FC/MC62D 1.00 1.01 1.00
Y*(8,L)C*C20 FC/MC62D 1.00 0.97 0.96
Y*9C*C20 FC/MC62D 0.99 0.96 0.98
Y*9C*D20 FC/MC62D 0.99 0.96 0.97
G*9V*C20 FC/MC62D 0.99 0.96 0.98
G*9V*D20 FC/MC62D 0.99 0.96 0.97
