271457-YTG-B-0908

2

Johnson Controls Unitary Products

All dimensions are in inches. They are subject to change with-
out notice. Certified dimensions will be provided upon request.

Physical and Electrical Data

MODEL

YZB1811

YZB02411

YZB03011

YZB03611

YZB04211

YZB04811

YZB06012

Unit Supply Voltage

208/230 – 1 – 60

Normal Voltage Range

1

187 to 252

Minimum Circuit Ampacity

14.2

18.8

22.0

25.6

32.1

35.3

37.5

Max. Overcurrent Device Amps

2

25

30

35

40

50

60

60

Min. Overcurrent Device Amps

3

15

20

25

30

35

40

40

Compressor Type

4

Scroll

Scroll

Scroll

Scroll

Scroll

Scroll

Scroll

Compressor Amps

Rated Load

11.0

14.7

16.4

19.3

24.5

27.0

25.0

Locked Rotor

51

60

73

88

105

113

150

Crankcase Heater

No

No

No

No

No

No

No

Fan Motor Amps

Rated Load

0.5

0.5

1.5

1.5

1.5

1.5

1.5

Fan Diameter Inches

22

22

22

22

22

22

24

Fan Motor

Rated HP

1/15

1/15

1/4

1/4

1/4

1/4

1/4

Nominal RPM

850

850

850

850

850

850

850

Nominal CFM

2,050

2,250

3,200

3,250

3,250

3,500

3,500

Coil

Face Area Sq Ft

14.86

17.15

17.15

20.58

20.58

20.58

23.58

Rows Deep

1

1

1

1

1

2

2

Fin /Inch

22

22

22

22

22

22

18

Liquid Line Set OD (Field Installed)

3/8

3/8

3/8

3/8

3/8

3/8

3/8

Vapor Line Set OD (Field Installed)

3/4

3/4

3/4

3/4

7/8

7/8

7/8

Unit Charge (Lbs - Oz)

5

7-1

7-10

7-9

9-5

9-2

12-5

16-8

Charge Per Foot, oz.

0.62

0.62

0.62

0.62

0.67

0.67

0.67

Operating Weight Lbs

175

190

195

220

220

260

265

1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4. All scrolls listed with superscript “B” are Bristol scrolls. All scrolls listed with superscripts “C” are Copeland scrolls.
5. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet,

add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.

VAPOR

LIQUID

2-3/8

3-1/8

6-1/2

C

A

B

DIMENSIONS

Unit

Model

Dimensions

(Inches)

Refrigerant

Connection

Service Valve Size

A B

C

Liquid

Vapor

018

29-1/2

37

31

3/8”

3/4”

024

33-1/2

37

31

030

33-1/2

37

31

036

39-1/2

37

31

042

39-1/2

37

31

7/8”

048

39-1/2

37

31

060

39-1/2

42

34
