Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO.
YZB04211
INDOOR COIL MODEL NO.
FC/MC/PC/UC48
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
1200
1400
1600
MBTUH
KW
C.O.P.
MBTUH
KW
C.O.P.
MBTUH
KW
C.O.P.
60
60
47.3
2.2
6.3
48.3
2.1
6.7
49.3
2.0
7.2
70
46.4
2.4
5.6
47.5
2.3
6.0
48.6
2.2
6.4
80
45.6
2.6
5.0
46.7
2.6
5.4
47.9
2.5
5.7
47
60
44.3
3.9
3.3
45.7
4.0
3.3
47.1
4.1
3.3
70
42.0
3.4
3.6
43.0
3.4
3.7
44.0
3.5
3.7
80
39.8
3.0
3.9
40.3
2.9
4.1
40.8
2.8
4.3
40
60
39.9
2.6
4.5
41.6
2.5
4.9
43.3
2.4
5.2
70
38.3
2.9
3.9
39.8
2.8
4.2
41.3
2.7
4.5
80
36.8
3.1
3.4
38.0
3.0
3.7
39.3
3.0
3.9
30
60
33.5
2.8
3.5
34.3
2.7
3.7
35.2
2.6
3.9
70
32.0
3.0
3.1
33.2
3.0
3.3
34.4
2.9
3.5
80
30.6
3.3
2.7
32.1
3.3
2.9
33.7
3.2
3.1
17
60
29.1
3.0
2.8
29.5
3.0
2.9
29.8
2.9
3.0
70
28.3
3.4
2.5
28.4
3.3
2.5
28.5
3.2
2.6
80
27.4
3.7
2.2
27.3
3.6
2.2
27.2
3.5
2.3
10
60
24.1
3.2
2.2
24.9
3.1
2.3
25.8
3.1
2.5
70
22.6
3.5
1.9
23.1
3.4
2.0
23.6
3.4
2.1
80
21.2
3.8
1.6
21.3
3.8
1.7
21.3
3.7
1.7
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler
Coil
MBH
KW
COP
MA14D
FC/MC48D
1.00
0.98
1.00
MA16C
FC/MC48C
1.00
0.98
1.00
MV16C
FC/MC48C
1.00
0.98
1.00
MV20D
FC/MC48D
1.00
0.98
1.00
AHP/SHP48
–
1.00
0.98
1.00
AV/SV48
–
1.00
0.94
1.04
–
HC48
1.00
0.97
1.00
–
HD48
1.00
0.97
1.00
Variable Speed
Furnace
Coil
MBH
KW
COP
PV8*C16
FC/MC/PC48C
1.00
0.97
1.00
PV8*C20
FC/MC/PC48C
1.00
0.97
1.00
PV8*C20
HC48
1.00
0.97
1.00
PV8*C20
HD48
1.00
0.97
1.00
P(C,V)9*C16
FC/MC/PC48C
1.00
0.95
1.02
P(C,V)9*C20
FC/MC/PC48C
1.00
0.95
1.02
P(C,V)9*C20
HC48
1.00
0.97
1.00
P(C,V)9*C20
HD48
1.00
0.97
1.00
P(C,V)9*D20
FC/MC/PC48D
1.00
0.95
1.02
Y*(8,L)C*C16
FC/MC/PC48C
0.99 1.04 0.95
Y*(8,L)C*C20
FC/MC/PC48C
0.99 1.04 0.95
Y*9C*C16
FC/MC/PC48C
0.99 1.03 0.96
Y*9C*C20
FC/MC/PC48C
0.99 1.03 0.97
Y*9C*D20
FC/MC/PC48D
0.99 1.04 0.96
Y*(8,L)C*B12
HD48
0.97 0.91 1.07
Y*(8,L)C*C16
HD48
0.97 0.94 1.03
Y*(8,L)C*C20
HD48
0.97 0.95 1.02
Y*9C*B12
HD48
0.95 0.86 1.10
Y*9C*C16
HD48
0.97 0.93 1.05
Y*9C*C20
HD48
0.97 0.93 1.05
Y*9C*D20
HD48
0.97 0.94 1.03
Y*(8,L)C*C16
UC48C
1.00 1.07 0.93
Y*(8,L)C*C20
UC48C
0.99 1.07 0.93
Y*9C*C16
UC48C
1.00 1.06 0.94
Y*9C*C20
UC48C
1.00 1.06 0.95
Y*9C*D20
UC48D
1.00 1.06 0.94
G*9V*C16
FC/MC/PC48C
0.99 1.03 0.96
G*9V*C20
FC/MC/PC48C
0.99 1.03 0.97
G*9V*D20
FC/MC/PC48D
0.99 1.04 0.96
G*9V*B12
HD48
0.95 0.86 1.10
G*9V*C16
HD48
0.97 0.93 1.05
G*9V*C20
HD48
0.97 0.93 1.05
G*9V*D20
HD48
0.97 0.94 1.03
G*9V*C16
UC48C
1.00 1.06 0.94
G*9V*C20
UC48C
1.00 1.06 0.95
G*9V*D20
UC48D
1.00 1.06 0.94
Variable Speed
Furnace
Coil
MBH
KW
COP
