Prestige 100WH Internet Access Router
6-3 Chapter 6 Dial-in Server Applications
6.2 LAN-to-LAN Application
Your Prestige can also be used as a LAN-to-LAN server. This application allows your
Prestige to connect two geographically separate LANs. For your Prestige to be set up as a
LAN-to-LAN server, you need to configure the Default Dial-In Setup to set the operational
parameters for incoming calls. Additionally, you will have to create a remote node for the
router on the remote network (See Chapter 5 - Remote Node Configuration).
An example of your Prestige being used as a LAN-to-LAN server is shown in Figure 6-2.
Figure 6-2. Example of a LAN-to-LAN Application
Remote Network Local Network
LAN-to-LAN
Server
Modem
ISDN TA
Modem / ISDN TA
Prestige 100WH
Prestige 100WH
Modem
ISDN TA
Modem / ISDN TA
