Prestige 100WH Internet Access Router
1-5 Chapter 1 Getting to Know Your Internet Access Router
1.4.2 Front Panel LEDS
The LED indicator lights on the front panel indicate the operational status of your Prestige.
The following table describes the LED functions:
Table 1-1. LED Functions
LED Function Indicator
Status Active Description
PWR Power LED Green On Power is being applied to the Prestige.
RUN Running
Status LED Green Blinking The Prestige is functioning properly.
COL Collisions Green On Transmission collisions have occurred
on the LAN.
On An active station is connected to the
port.
ETHER
-NET
1,2,3,4 Link status
& Activity Green
Blinking The station connected to the port is
transmitting.
RDY Ready Green On The WAN port is ready.
CD Carrier
Detect Green On The connection is ready for data
transfer.
TXD Transmit Green Blinking Traffic is being transmitted from the
Prestige.
RXD Receive Green Blinking Traffic is being received from the WAN
device.
RTS Request to
Send Green On The Prestige is ready to receive data.
WAN
Port
CTS Clear to
Send Green On The WAN device is ready to receive
data.
