Prestige 100WH Internet Access Router
1-8
Chapter 1 Getting to Know Your Internet Access Router
1.6.3 LAN-to-LAN Connection
Your Prestige can dial to and answer calls from another remote access router. A typical LAN-
to-LAN application for your Prestige is to connect the Corporate Office LAN with the Branch
Office, as shown in Figure 1-4.
Figure 1-4.
LAN-to-LAN Connection Application
Branch Office LAN
E t h e r n e t L A N
E t h e r n e t L A N
Corporate LAN
Modem
ISDN TA
Modem / ISDN TA
Prestige Router
PSTN/ISDN Network
Prestige 100WH
