Page 31
Prestige 100WH Internet Access Router
2-3
Chapter 2 Hardware Installation & Initial Setup
2.3 Connect your Internet Access Router
2.3.1 Prestige 100WH Connections
Figure 2-1.
Connect Prestige 100WH
POWER
CONSOLE
ETHERNET
4
3
2
1
WAN
Ethernet LAN
Computer
Power
Adapter
Power
Outlet
Modem
ISDN TA
CSU/DSU
PSTN/ISDN Network
Fractional T1/E1
Modem / ISDN TA
