Prestige 100WH Internet Access Router
2-14 Chapter 2 Hardware Installation & Initial Setup
2.9.2 Advanced WAN Port Setup
The Advanced WAN Port Setup Menu allows you to configure the AT Commands for the
WAN device and the call control parameters.
Step 1. In Menu 2.1, move the cursor to the Advanced Setup field and press the space bar
to select [Yes], then press [Enter]
.
Step 2. When Menu 2.1.1 appears, fill in the appropriate AT commands and call control
parameters, as shown in Figure 2-8.
Figure 2-8. Menu 2.1.1 - Advanced WAN Setup
Menu 2.1.1 - Advanced WAN Setup
AT Command Strings:
Dial=atdt
Drop= --+++--ath
Answer= ata
Drop DTR When Hang Up= Yes
AT Response string:
CLID= NMBR
Called= TO
Speed= CONNECT
Call Control:
Dial Timeout(sec)= 60
Retry Counter= 0
Retry Interval(sec)= N/A
Drop Timeout(sec)= 20
Call Back Delay(sec)= 15
Enter here to CONFIRM or ESC to CANCEL:
