Prestige 100WH Internet Access Router
10-2 Chapter 10 System Maintenance
10.1 System Status
System Status is a tool to monitor your Prestige. Specifically, it gives you information on the
status of your system software version, modem, and number of packets sent and received, as
shown in Figure 10-2.
Figure 10-2. Menu 24.1 - System Maintenance - Status
Follow the procedure below to go to the System Status Menu.
Step 1. Select option 24 from the Main Menu to access Menu 24 - System Maintenance.
Step 2. From Menu 24, select option [1. System Status].
Step 3. There are 3 possible commands in Menu 24.1 - System Maintenance - Status.
l Entering 1 will disconnect the current call;
l Entering 9 will reset the counters;
l and [Esc] will exit this screen.
Menu 24.1 -- System Maintenance - Status
Port
1
Status
Idle Speed
0Kbps TXPkts
0
RXPkts
0
Errs
0
TxB/s
0
RxB/s
0
Up Time
0:00:00
Total Outcall Time: 0:00:00
Ethernet:
Status: 10M/Full Duplex
TX Pkts: 26
RX Pkts: 0
Collisions: 0
Name: p100MH
RAS S/W Version: V2.11(I.01)b11 | 5/21/98
Ethernet Address: 00:a0:c5:00:10:32
LAN Packet Which Triggered Last Call:
Press Command:
CMDS: 1-Drop Port1 2-Drop Port2 3-Drop Port3 8-Drop All 9-Rst Cnt ESC-Exit
