40 LCD Panel Operation
Status Display Unit
Transmitted Shaping MIN (MAX)
Received Shaping MIN (MAX)
Transmitted filter index 0~10
Received filter index 0~10
On-line Status Screen 9
Status Display Unit
Transmitted Carrirr 1959 Hz
Received Shaping 1959 Hz
Transmitted Baud rate 3429 Baud
Received Baud rate 3429 Baud
On-line Status Screen 10
Status Display Unit
Probing Result Channel
Spectrum
probed at V34
phase two.
Pressing the left or right arrow key in any one of the ON-LINE
STATUS screens will cause the LCD to scroll through the four screens.
We will discuss the ON-LINE -STATUS screens 2, 3, and four in
more detail in the section Line Condition Status Display in chapter ten.
Pressing the ENTER key while in any ON-LINE STATUS screen will
cause the LCD to display the following:
DISCONNECT ?
z YES NO
DISCONNECTING……
