LCD Panel Operation 29
computer/terminal or any key pad operation from the front panel. On
the LCD screen, there are four on-screen buttons:
D Dialing operation with submenus.
R Redial last number.
O Originate mode on-line.
A Answer mode on-line.
The cursor is blinking above one of these on-screen buttons, a dark
rectangle which may be moved using the keys next to the display. The
modem also displays the current status and settings in the idle screen:
Information Example
Link Option V34 (V.34)
Link Speed 33600 (bps)
Error Control V42 (implied by V.42bis)
Data Compression V42b (V.42bis)
Line Type DL (Dial-up line)
2LO (2-wired leased line originate mode)
2LA (2-wired leased line answer mode)
Data Format AS (asynchronous)
SD (Sychronous data)
S (Sychronous)
DTE Speed 115200 (bps)
ORG/Ans 2LO (2w leased line originate)
Panel Operation
Use the four arrow keys to manipulate the menu tree.
Left/Right arrow
keys used for horizontal item selection and option
selection.
Up arrow key also called the MENU key, is used for vertical
