112 Status Registers & Result Codes
Command bit dec hex Function and description
Ref.
24
18
ATX3
X3
32
20
ATX4
X4
40
28
ATX5, error control result code
enabled (Default)
X5
48
30
ATX6, error control result code
enabled
X6
56
38
ATX7, error control result code
enabled
X7
6
0
0
Display result code in numeric
format (see S35.7)
V0
64
40
Display result code in verbose
format
V1
7
0
0
Modem returns result code
Q0
128 80
Modem does not return result
code (see also S40.1)
Q1
S24=
bit dec hex Bit mapped register
2-0 0-7 0-7 Ring Volume control, increment
of 2 in decimal value
N0-7
6-4 16-
112
10-
70
Speaker volume control,
increments of 32 in decimal value
L0-7
S25=
0-
255
0-FF Specify the time delay that DTR
signal needs to be OFF before it
will be recognized, in 10 ms
units. If S25=0, the delay time is
set to 4 ms
+000
S26=
dec hex RTS/CTS delay
+000
0-
255
0-FF Set the delay, in 10 millisecond
units between the RTS and
modem’s CTS response in
synchronous mode (see ‘&Rn’
&Rn
