LCD Panel Operation 37
DISCONNECTING..........
1234567
The modem will then return to the IDLE STATUS screen. If the first
handshaking signal has been detected, the LCD screen will display:
HANDSHAKING............
1234567
If a connection has been made, the LCD will display the actual
connected status. These are V.34 data state screens:
V.34b 33600 33600
DL SNR= 41.5 CLC= 0
H >> 55820 51324 AS TXL=-11.0 RXL=-21.3
RTG= 0 RTR= 0 V42b/SREJ BLS= 256
FRG= 0 FRR= 0 BLR= 0 FRE=
0
NEC=-40.4 RTD= 0 PHJ= 0.0 FRO=- 0.0
FEC= -57.2 EFO= 0 EDL= 0
NLE= ON NLD=
ON
TSH=MIN
RSH=MIN
TRE= 64 CND=
64
TFI = 7 RTFI=
10
* *
TXC=1920 RXC=1920
TXB=3429 RXB=3429
PROBING
* *
ONote: The on-line status screens with“*” are available one in V.34
mode.
