38 LCD Panel Operation
On-line Status Screen 1
Status Display Unit/Meaning
Link Option V34b V.34bis
Line Speed 33600 bps/ TX/RX speed in V-34
Error control V42b V.42bis/only display in Non-V.34
mode
Line Type DL Dial-up Line
Data Format AS Asynchronous
Instant Transmission
Throughput 55820 bps/Blank in synchronous mode
Instant Receiving
Throughput 51324 bps/Link Speed in synchronous
mode
On-line Status Screen 2
Status Display Unit
Signal to Noise Ratio 30.9 dB
Receiving Signal level -25.1 dBm
Transmition Signal level -11 dBm
Carrier lost Counts 0
On-line Status Screen 3
Status Display Unit
Retrain Granted 0
Retrain RequesTed 0
FRN (Fast Rate reNegotiation )
Granted 0
FRN Requested 0
On-line Status Screen 4
