10 Installation
Power switch, turns the modem ON or OFF.
•
POWER JACK
Input terminal for power. Use the supplied AC adapter for U-336S
model. For U-336SA model you can use your power cord to
directly connect to the AC power outlet.
•
LINE
Dial-up line RJ-11 terminal jack, for connection to a 2-wire dial-up
or 2-wire leased line.
•
PHONE
RJ-11 terminal jack, for connection to a telephone set.
•
EIA-232D
Serial port DB25S connector, for connection to the serial port of a
DTE (computer/terminal). Pin assignments are listed in Chapter 12
Connector Pinouts for your reference. The signal-pin assignments
for RJ-11 phone jacks are also listed in Chapter 12 Connector
Pinouts.
Modem Connection
When you connect your U-336S modem to the power line, make sure
you only use the power adapter that is supplied with this unit. Use of
another adapter may not allow your modem to operate and could result
in serious damage to the unit.
This adapter is rated for direct connection to an AC power outlet.
Connect your modem as shown in Figure 2-5 U-336S Modem
Connections.
