Installation
1–26 975-0046-01-01
Wiring for Off-Grid Applications Using Additional Circuit
Breakers in the ACCB Only
The following diagram shows the complete wiring diagram for wiring the
ACCB and Sine Wave Plus Inverter inputs and outputs in an off-grid
application using additional circuit breakers in the ACCB for the outputs
and a 120 Vac generator for input. This diagram also includes the use of a
generator disconnect breaker in the ACCB. Wiring instructions are
provided for making ground connections first (
page 1–27 ), neutral
connections second ( page 1–28 ), and hot connections last ( page 1–29 ).
Figure 1-22 Wiring an Off-Grid Application Using Additional Circuit Breakers in the ACCB Only
WARNING: Shock Hazard
Ensure that all AC and DC power is not “live” before proceeding.
AC Loads
D D
Set Inverter OFF SRCH ON CHG
Sine Wave Plus Inverter / Charger
AC
IN
AC
OUT NEU IN
V O
U
T
NE
U O
U
T
NE
U 2
NE
U 1
AC
1 G
R
ID
AC
2 G
E N
AC TERMINAL
BLOCK
120V AC Generator
HOT NEU GND
To Primary
System Ground
D
Generator
Disconnect
Breaker
D
Neutral to
Ground Bond
Ground
Neutral
HOT (Owner supplied)
LEGEND
HOT (Factory installed) Additional AC Load
Circuit Breaker
