Specifications
975-0046-01-01 1–3
Specifications
Dimensions 15 1/8" (H) x 10 3/4" (W) x 8 7/8" (D)
(384 mm x 273 mm x 225 mm)
Weight 12 pounds (5 kg)
Shipping Weight 15 pounds (7 kg)
Operating Voltage 120 Vac
Breakers:
Bypass 60 Amp (SPST)
Inverter Input/Output 60 Amp (DPST)
Operating Temperature -10 to 60 °C (14 to 140 °F)
Storage Temperature -55 to +100 °C (-67 to 212 °F)
Enclosure Indoor rated
Finish Powdercoat
Color White
Regulatory Certified by CSA to UL 1741 and CSA
107.1-01
Figure 1-2 ACCB Dimensions (not to scale)
8 7/8"
(225 mm)
10 3/4"
(273 mm)
15 1/8"
(384 mm)
13 5/8"
(346 mm)
3/4"
(20 mm)
1 5/8"
(41 mm)
7 9/16"
(192 mm)
9 3/16"
(234 mm)
D D
5 3/8"
(137 mm)
