Installation
Chapter 1, “Installation” provides installation and wiring
instructions for the Sine Wave Plus AC Conduit Box ( ACCB ).
The following topics are covered in this chapter.
For this topic: See:
“Introduction” page 1–2
“Specifications” page 1–3
“Bypass Switch Assembly” page 1–4
“Code Compliance” page 1–5
“Installation Tools and Materials” page 1–5
“Wiring Scenarios” page 1–6
“Pre-installation” page 1–7
“Mounting the ACCB to the Inverter” page 1–14
“Pre-Wiring Preparation” page 1–15
“Off-Grid Wiring” page 1–18
through
page 1–29
“On-Grid Wiring” page 1–30
through
page 1–37
“Wiring for Dual Inverter Configurations” page 1–39
