WPA-1000 User’s Guide
59
C
H A P T E R
6
Product Specifications
6.1 Hardware
The following table summarizes the WPA-1000’s hardware features.
6.2 Firmware
The following table summarizes the WPA-1000’s firmware features
Table 14 Hardware Specifications
Dimensions (W x D x H) 190 x 130 x 33 mm
Device Weight 0.4kg
Power Specification 5 V DC 2A
Ethernet Ports Auto-negotiating: 10 Mbps or 100 Mbps in either half-duplex or full-duplex
mode.
Use crossover Ethernet cables.
Ports One 10/100 Ethernet LAN port with RJ-45 jack
Connector One VGA (D-sub 15 pin)
Antenna One external 2.95dBi antenna
Transmission Rate Up to 20 frames per second
Frame size 320 x 240
Operating Temperature 5º C ~ 40º C
Storage Temperature 0º C ~ 65º C
Operating Humidity 20% ~ 80% RH
Storage Humidity 5% ~ 95% RH
Distance between the
centers of the holes (for
wall mounting) on the
device’s back.
137 mm
Recommended type of
screws for wall-mounting
M4 Tap Screw, see Figure 34 on page 62 .
Table 15 Firmware Specifications
FEATURE DESCRIPTION
Default IP Address 192.168.1.10
Default Subnet Mask 255.255.255.0 (24 bits)
Default Passwords 1234
