Chapter 4 The Web Configurator Screens
WPA-1000 User’s Guide
44
• All Block: Only DHCP ports (UDP 67, UDP 68) are allowed through to WPA-1000 users
(U) via the WPA-1000 (W) from the company network (N) or the Internet. This means that
a DHCP server on the company network or the Internet can still assign IP addresses to
users but all other traffic is blocked between the company network or the Internet and
WPA-1000 users via the WPA-1000.
• All Pass: All traffic (ports) is allowed between the company network or the Internet and
WPA-1000 users via the WPA-1000.
• Internet Only: Only primary UDP/TCP connections are allowed between the company
network or the Internet and WPA-1000 users via the WPA-1000.
UDP Ports Allowed: 67, 68, 53
TCP Ports Allowed: 20, 21, 25, 70, 80, 81, 82, 83, 110, 443, 554, 1040, 1047, 1080, 8080,
8088, 3128
Figure 25 Gatekeeper
4.6.3 Network Screen Configuration
Click Network from the main web configurator screen.
W
P
S U
INTERNET
