Chapter 1 Introducing the WPA-1000
WPA-1000 User’s Guide
22
1.1.2 Wireless Connection Via Another AP
Meeting participants can wirelessly access the WPA-1000 (W) via an AP (A) as shown in the
next figure. The AP can be connected to the WPA-1000 directly or via a switch (S).
Figure 2 Wireless Indirect
1.1.3 Wired Direct
Meeting participants can directly access the WPA-1000 (W) via a switch (S) as shown in the
next figure.
Figure 3 Wired
1.2 Managing the WPA-1000
Web Configurator. This is recommended for everyday management of the WPA-1000 using a
(supported) web browser. See
Section 2.4 on page 28 .
A
W
S
INTERNET
W
S
