Chapter 4 The Web Configurator Screens
WPA-1000 User’s Guide
47
Figure 28 Network
View the IP address on your notebook by typing ‘ipconfig’ in the command line window. The
following sample display appears.
Figure 29 Example Notebook Network IP Addresses
The top IP address is the IP address your notebook received from your company’s DHCP
server via its wired connection to (S).
The bottom IP address is the IP address your notebook received from the WPA-1000’s DHCP
server via its wireless connection to (W).
Ethernet adapter Local Area Connection:
Connection-specific DNS Suffix . : zyxel.com
IP Address. . . . . . . . . . . . : 172.16.10.10
Subnet Mask . . . . . . . . . . . : 255.255.255.0
Default Gateway . . . . . . . . . : 172.16.10.254
Ethernet adapter ZyXEL:
Connection-specific DNS Suffix . :
IP Address. . . . . . . . . . . . : 192.168.1.11
Subnet Mask . . . . . . . . . . . : 255.255.255.0
Default Gateway . . . . . . . . . : 192.168.1.10
