Chapter 4 The Web Configurator Screens
WPA-1000 User’s Guide
40
The table below describes the labels on the screen.
4.5 Device Setup
Use these screens to change projection settings and passwords.
4.5.1 Device Config
Click on Device Config. Use this screen to change projection settings.
4.5.2 Resolutions
Resolution is the number of pixels that the projector is capable of displaying. Pixels are the
individual dots that make up the image on your computer.
SVGA, XGA, and WXGA are the standards of resolution supported by the WPA-1000 at the
time of writing. SVGA and XGA are terms that describe standard (4:3 aspect ratio) resolutions
used by computers and projectors. WXGA is a term that describes widescreen (16:9 aspect
ratio) resolutions used by home cinema projectors.
Table 8 Status
LABEL DESCRIPTION
Device Information
Model Name The model name is WPA-1000. This cannot be changed and is different to the
SSID which identifies your device in a wireless network.
Firmware Version This shows the current WPA-1000 firmware version.
Network Status
IP Address This is the current IP address of the WPA-1000. 192.168.1.10 is the default IP
address. If the WPA-1000 is connected to your network and is set to receive an
IP address automatically, then it will show the IP address it received here. This IP
address is also displayed as the Server IP in the Standby screen.
Subnet Mask This is the subnet mask for WPA-1000.
Default Gateway This is the IP address of the gateway. The gateway is an immediate neighbor of
your WPA-1000.
Wireless MAC
Address
This is the MAC address of the built-in WPA-1000 wireless adapter.
Wired MAC
Address
This is the MAC address of the WPA-1000 Ethernet port.
Device Status
Projecting Status This is the status of the connected projector. It can be either Waiting for
Projecting or Projecting.
Users This shows how many people are logged into the WPA-1000. The maximum
number of meeting participants allowed to log in at one time is 128.
