Wpa-1000 hardware, 1 rear panel, Chapter 2 wpa-1000 hardware – ZyXEL Communications WPA-1000 User Manual
Page 25: Figure 4 rear panel connections
WPA-1000 User’s Guide
25
C
H A P T E R
2
WPA-1000 Hardware
This chapter introduces the rear panel, front panel, standby screen and main web configurator
screen.
2.1 Rear Panel
See the Quick start Guide for details on how to make rear panel connections.
Figure 4 Rear Panel Connections
POWER ON|OFF
VGA
RESET
LAN
