ZyXEL Communications ADSL 2+ Gateway P-660HW-T1 - Manual (Page 81)

P-660H/HW/W-T Series User’ Guide
81 Chapter 5 Wireless LAN
• A computer with an IEEE 802.11 a/b/g wireless LAN adapter and equipped with a web
browser (with JavaScript enabled) and/or Telnet.
• A wireless station computer must be running IEEE 802.1x-compliant software. Not all
Windows operating systems support IEEE 802.1x (see the Microsoft web site for details).
For other operating systems, see their documentation. If your operating system does not
support IEEE 802.1x, then you may need to install IEEE 802.1x client software.
• An optional network RADIUS server for remote user authentication and accounting.
Select Authentication Required in the Wireless Port Control field and 802.1x in the Key
Management Protocol field to display the next screen.
Figure 26 Wireless LAN: 802.1x/WPA: 802.1xl
The following table describes the labels in this screen.
Table 16 Wireless LAN: 802.1x/WPA: 802.1x
LABEL DESCRIPTION
Wireless Port
Control
To control wireless station access to the wired network, select a control method
from the drop-down list box. Choose from No Authentication Required,
Authentication Required and No Access Allowed.
The following fields are only available when you select Authentication Required.
ReAuthentication
Timer
(in Seconds)
Specify how often wireless stations have to reenter usernames and passwords in
order to stay connected. This field is activated only when you select
Authentication Required in the Wireless Port Control field.
Enter a time interval between 10 and 9999 seconds. The default time interval is
1800 seconds (30 minutes).
Note: If wireless station authentication is done using a RADIUS
server, the reauthentication timer on the RADIUS server has
priority.
