ZyXEL Communications ADSL 2+ Gateway P-660HW-T1 - Manual (Page 289)

P-660H/HW/W-T Series User’ Guide
289 Chapter 30 SNMP Configuration
The port number is its interface index under the interface group.
5 authenticationFailure (defined in
RFC-1215)
A trap is sent to the manager when receiving any
SNMP gets or sets requirements with wrong
community (password).
6 whyReboot (defined in ZYXEL-MIB) A trap is sent with the reason of restart before
rebooting when the system is going to restart (warm
start).
6a For intentional reboot : A trap is sent with the message "System reboot by
user!" if reboot is done intentionally, (for example,
download new files, CI command "sys reboot", etc.).
Table 101 Ports and Permanent Virtual Circuits
PORT PVC (PERMANENT VIRTUAL CIRCUIT)
1 Ethernet LAN
2 1
3 2
… …
13 12
14 xDSL
Table 100 SNMP Traps (continued)
TRAP # TRAP NAME DESCRIPTION
