P-660H/HW/W-T Series User’ Guide
Chapter 16 Media Bandwidth Management Advanced Setup 188
4 The Prestige assigns any remaining unbudgeted bandwidth to traffic that does not match
any of the bandwidth classes.
16.8 The Main Media Bandwidth Management Screen
Click Media Bandwidth Mgnt. to display the main Media Bandwidth Management screen
as shown.
Figure 92 Media Bandwidth Mgnt.
The following table describes the links in this screen.
16.9 Configuring Summary
Click Media Bandwidth Management, Summary to open the screen as shown next.
Enable bandwidth management on an interface and set the maximum allowed bandwidth for
that interface.
Refer to Section 16.1 on page 182 for more information.
Table 55 Media Bandwidth Mgnt.
LINK DESCRIPTION
Summary Click this link to display a screen where you can enable bandwidth management
on an interface and set the maximum allowed bandwidth for that interface.
Class Setup Click this link to display a screen thwere you can configure bandwidth classes.
Monitor Click this link to display a screen wehre you can view bandwidth usage.
