P-660H/HW/W-T Series User’ Guide
Chapter 29 Filter Configuration 274
29.2 Configuring a Filter Set for the Prestige
To configure a filter set, follow the steps shown next.
1 Enter 21 in the main menu to display Menu 21 – Filter and Firewall Setup.
2 Enter 1 to display Menu 21.1 – Filter Set Configuration as shown next.
Figure 166 Menu 21 Filter Set Configuration
3 Type the filter set to configure (no. 1 to 12) and press [ENTER] .
4 Type a descriptive name or comment in the Edit Comments field and press [ENTER].
5 Press [ENTER] at the message “ Press ENTER to confirm…” to display Menu 21.1.1 –
Filter Rules Summary (that is, if you selected filter set 1 in menu 21.1).
Figure 167 NetBIOS_WAN Filter Rules Summary
Menu 21.1 - Filter Set Configuration
Filter
Set # Comments Set # Comments
------ ----------------- ------ -----------------
1 _______________ 7 _______________
2 _______________ 8 _______________
3 _______________ 9 _______________
4 _______________ 10 _______________
5 _______________ 11 _______________
6 _______________ 12 _______________
Enter Filter Set Number to Configure= 0
Edit Comments= N/A
Press ENTER to Confirm or ESC to Cancel:
Menu 21.1.2 - Filter Rules Summary
# A Type Filter Rules M m n
- - ---- --------------------------------------------------------------- -
- -
1 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=137 N D N
2 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=138 N D N
3 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=139 N D N
4 Y IP Pr=17, SA=0.0.0.0, DA=0.0.0.0, DP=137 N D N
5 Y IP Pr=17, SA=0.0.0.0, DA=0.0.0.0, DP=138 N D N
6 Y IP Pr=17, SA=0.0.0.0, DA=0.0.0.0, DP=139 N D F
Enter Filter Rule Number (1-6) to Configure:
