P-660H/HW/W-T Series User’ Guide
297 Chapter 32 System Information and Diagnosis
The following table describes the fields present in Menu 24.1 — System Maintenance —
Status which are read-only and meant for diagnostic purposes.
Figure 188 Menu 24.1 System Maintenance : Status
The following table describes the fields present in Menu 24.1 — System Maintenance —
Status.
Menu 24.1 - System Maintenance - Status 23:08:47
Sat. Jan. 01, 2000
Node-Lnk Status TxPkts RxPkts Errors Tx B/s Rx B/s Up
Time
1-ENET N/A 0 0 0 0 0 0:00:00
2 N/A 0 0 0 0 0 0:00:00
3 N/A 0 0 0 0 0 0:00:00
4 N/A 0 0 0 0 0 0:00:00
5 N/A 0 0 0 0 0 0:00:00
6 N/A 0 0 0 0 0 0:00:00
7 N/A 0 0 0 0 0 0:00:00
8 N/A 0 0 0 0 0 0:00:00
My WAN IP (from ISP): 0.0.0.0
Ethernet: WAN:
Status: 100M/Full Duplex Tx Pkts: 5731 Line Status: Down
Collisions: 0 Rx Pkts: 8314 Upstream Speed: 0 kbps
CPU Load = 25.52% Downstream Speed: 0 kbps
Press Command:
COMMANDS: 1-Reset Counters TAB-Next Page ESC-Exit
Table 105 Menu 24.1 System Maintenance: Status
FIELD DESCRIPTION
Node-Lnk This is the node index number and link type. Link types are: PPP, ENET, 1483.
Status This shows the status of the remote node.
TxPkts The number of transmitted packets to this remote node.
RxPkts The number of received packets from this remote node.
Errors The number of error packets on this connection.
Tx B/s This shows the transmission rate in bytes per second.
Rx B/s This shows the receiving rate in bytes per second.
Up Time This is the time this channel has been connected to the current remote node.
My WAN IP
(from ISP)
This is the IP address of the ISP remote node.
Ethernet This shows statistics for the LAN.
Status This shows the current status of the LAN.
Tx Pkts This is the number of transmitted packets to the LAN.
Rx Pkts This is the number of received packets from the LAN.
