P-660H/HW/W-T Series User’ Guide
Chapter 36 IP Policy Routing 332
36.5 Applying an IP Policy
This section shows you where to apply the IP policies after you design them.
36.5.1 Ethernet IP Policies
From Menu 3 — Ethernet Setup, type 2 to go to Menu 3.2 — TCP/IP and DHCP Ethernet
Setup.
You can choose up to four IP policy sets (from 12) by typing their numbers separated by
commas, for example, 2, 4, 7, 9.
Gateway addr Defines the outgoing gateway address. The gateway must be on the same
subnet as the Prestige if it is on the LAN, otherwise, the gateway must be the IP
address of a remote node. The default gateway is specified as 0.0.0.0.
Type of Service Set the new TOS value of the outgoing packet. Prioritize incoming network traffic
by choosing No Change, Normal, Min Delay, Max Thruput, Max Reliable or
Min Cost.
Precedence Set the new outgoing packet precedence value. Values are 0 to 7 or No
Change.
Log Press [SPACE BAR] and then [ENTER] to select Yes to make an entry in the
system log when a policy is executed.
When you have completed this menu, press [ENTER] at the prompt “ Press ENTER to Confirm
or ESC to Cancel: ” to save your configuration, or press [ESC] at any time to cancel.
Table 116 Menu 25.1.1 IP Routing Policy (continued)
FIELD DESCRIPTION
