9-4
Operation
9.2. A/B Switching - Text Interface
When using the Text Interface, all A/B switching functions are performed by invoking
simple, ASCII commands. The Text Interface includes a Help Menu, which summarizes
all available AFS-16 commands. To display the Text Interface Help Menu (Figure 9.1),
type
/H and press [Enter].
Note: When the Help Menu is displayed by an account that permits SuperUser,
User or ViewOnly level commands, the screen will not include commands that
are only available to Administrators.
9.2.1. The Circuit Status Screen - Text Interface
When you login to the AFS-16 command mode via the Text Interface, the first screen
displayed after login is the Circuit Status Screen. The Circuit Status Screen lists
the current status of the AFS-16’s Circuit Modules, and also displays the current
temperature, Monitor/Alarm Input status, Alarm Contact Output status and the
user-defined Site I.D. Message. The Circuit Status Screen will be re-displayed each time
a command is successfully executed.
COMMAND MENU: Version 1.00
DISPLAY CONFIGURATION
/S Circuit Status /F System Parameters
/SG Circuit Group Status /P Port Parameters
/SN Network Status /PC Circuit Parameters
/L Log /G Circuit Group Parameters
/J [*] Site ID /N Network Configuration
/PNA Ping No Answer
CONTROL /AC Alarm Configuration
/X Exit Command Mode /I Reboot System
/C Connect - Local /UF Upgrade Firmware
/D Disconnect Port /TEST Test Network Options
/TA Switch To Circuit Position A +-------------------------------+
/TB Switch To Circuit Position B | n Port #/name |
/T Switch To Circuit Position | s s+s s:s Circuit #/name |
/DC Default Circuit Position | c c,c c-c Circuit #/name |
/U Send Parameter File | p Position (A or B) |
/K Send SSH Keys | k Key type (1-3) |
/UL Unlock (Invalid Access) | * “all” |
| <> Required entry |
| [] Optional entry |
Add ,Y to bypass “Sure?” +-------------------------------+
AFS>
Figure 9.1: The Help Menu (Administrator Mode; Text Interface)
