13-3
Operation via SNMP
13.4. Circuit Control via SNMP
13.4.1. Controlling Circuits
A/B Switching and Default commands can be issued for circuits via SNMP. Circuits are
arranged in a table of N rows, where N is the number of circuits in the system. Circuit
parameters are described below.
• circuitTable::circuitID – String indicating the circuit's ID
• circuitTable::circuitName - String indicating the circuit's user-defined name.
• circuitTable::circuitStatus – Current state of the circuit
0 Switch Position B
1 Switch Position A
• circuitTable::circuitAction – Action to be taken on circuit
1 Mark to Switch to A (does not execute)
2 Mark to Switch to B (does not execute)
3 N/A
4 Mark to DEFAULT Circuit (does not execute)
5 Mark to Switch to A and execute circuit actions
6 Mark to Switch to B and execute circuit actions
7 N/A
8 Mark to DEFAULT Circuit and execute circuit actions
Set circuitTable::circuitAction to desired action, as specified by values 1-4
above, for each circuit index the action is to be applied to. For the last circuit you wish
to set before executing the commands, use values 5-8 instead, which will invoke the
requested commands all at once.
13.4.2. Controlling Circuit Groups
A/B Switching and Default commands can be issued for circuit groups via SNMP. Circuit
Groups are arranged in a table of 54 rows, one row for each circuit group in the system.
Circuit Group parameters are described below.
• circuitGroupTable::circuitGroupName – String indicating the circuit groups
name
• circuitGroupTable::circuitGroupAction – Action to be taken on circuit
group
1 Mark to Switch to A (does not execute)
2 Mark to Switch to B (does not execute)
3 N/A
4 Mark to DEFAULT Circuit (does not execute)
5 Mark to Switch to A and execute circuit group actions
6 Mark to Switch to B and execute circuit group actions
7 N/A
8 Mark to DEFAULT Circuit and execute circuit group actions
Set circuitGroupTable::circuitGroupAction to desired action, as specified by
values 1-4 above, for each circuit group index the action is to be applied to. For the last
circuit group you wish to set before executing the commands, use values 5-8 instead,
which will invoke the requested commands all at once.
