8-1
8. The Status Screens
The Status Screens are used to display status information about the AFS-16 hardware
and firmware, Network Port, Circuit Modules, Circuit Groups and other features. The
Status Screens are available via both the Text Interface and Web Browser Interface.
8.1. Product Status
The Product Status Screen lists the model number, power rating and software version
for your local AFS-16 unit. To display the Product Status Screen via the Text Interface,
type
/J * and then press [Enter]. To display the Product Status Screen via the Web
Browser Interface, click on the "Product Status" link. The Product Status Screen lists the
following items:
• Product: The make/model number of the AFS-16 unit.
• SW Version: The software version that is currently installed on the AFS-16 unit.
• PIC Version: The version of the micro controller chip, that is present on the Control
Module.
8.2. The Network Status Screen
The Network Status screen shows activity at the AFS-16's virtual network ports, and
lists the TCP Port Number, Active/Free Status and current user name for each virtual
network port. To view the Network Status Screen, you must access command mode
using a password that permits access to Administrator Level commands. To display the
Network Status Screen via the Text Interface, type
/SN and press [Enter]. To display the
Network Status Screen via the Web Browser Interface, click on the Network Status link.
The Network Status Screen lists the following items:
• Port: The virtual network port for each connection.
• TCP Port: The TCP Port number for each connection.
• Status: This column will read "Free" if no users are currently connected to the
corresponding port, or "Active" if a user has currently accessed command mode via
this port.
• User Name: The user name for the account that has currently accessed command
mode via this port. Note that when the Network Status Screen is viewed via the Text
Interface, usernames that are longer than 22 characters will be truncated and the
remaining characters will be displayed as two dots (..).
