13-4
Operation via SNMP
13.5. Viewing AFS-16 Status via SNMP
Status of various components of the AFS-16 can be retrieved via SNMP. Circuit Status,
and Environmental Status are currently supported.
13.6.1. Circuit Status
The status of each circuit in the system can be retrieved using the command below.
• circuitTable::circuitStatus – The status of the circuit.
0 Switch Position B
1 Switch Position A
155 No Circuit Installed in this Slot
• circuitTable::circuitReason – Returns a numeric code, which describes the
reason for the last successful A/B switching operation as follows:
0 Power Up
1 User
2 PNA
3 External Alarm
4 Circuit Switch
5 Control Switch
6 Demo
13.6.2. Unit Environment Status
The temperature status and Control Module Jumper status can be retrieved. The
environmentUnitTable contains one row.
• environmentUnitTable::environmentUnitTemperature – The temperature
of the AFS-16 unit.
• environmentUnitTable::environmentUnitName – Returns the specific
model number for the AFS-16 unit.
• environmentUnitTable::environmentUnitMonitorAlarm – Returns the
current state of the Monitor Input Signal.
0 Monitor Input Signal is Low.
1 Monitor Input Signal is High
