C-1
Appendix C
Configuration Parameters
Table C–1 describes the valid configuration parameters for the programmers discussed in this manual.
Use of invalid parameters will result in programming errors.
Table C–1. Valid Configuration Parameters
Device
Family Device
1st Name
Start Size Type VCC VPP Pdt
Ctrl
Reg.
Family
Code
Block
Erase Program
Alg.
27128 TMS27C128 0000h 4000h EPROM 6 12.5 01 00h 42h No 0s only
27256 TMS27C256 0000h 8000h EPROM 6 12.5 01 00h 43h No 0s only
2732 TMS2732A 0000h 1000h EPROM 5 21 10 00h 40h No 0s only
2764 TMS2764 0000h 2000h EPROM 6 21 01 00h 41h No 0s only
2764 TMS27C64 0000h 2000h EPROM 6 12.5 01 00h 41h No 0s only
7742 TMS7742 F000h 1000h EPROM 5 21 10 00h 20h No 0s only
TMS370 16K_PE 4000h 4000h EPROM 5 12.5 01 1Ch 11h No 0s only
TMS370 256_DEE 1F00h 0100h EEPROM 5 12 10 1Ah 10h to 0s 1s only
TMS370 4K_PEE 7000h 1000h EEPROM 5 12 10 1Ch 10h to 0s 1s only
TMS370 512_DEE 1E00h 0200h EEPROM 5 12 10 1Ah 10h to 0s 1s only
TMS370 C010 1F00h 0100h EEPROM 5 12 10 1Ah 10h to 0s 1s only
TMS370 C050 1F00h 0100h EEPROM 5 12 10 1Ah 10h to 0s 1s only
TMS370 C052 1F00h 0100h EEPROM 5 12 10 1Ah 10h to 0s 1s only
TMS370 C056 1E00h 0200h EEPROM 5 12 10 1Ah 10h to 0s 1s only
TMS370 C250 1F00h 0100h EEPROM 5 12 10 1Ah 10h to 0s 1s only
TMS370 C256 1E00h 0200h EEPROM 5 12 10 1Ah 10h to 0s 1s only
TMS370 C756 1E00h 0200h EEPROM 5 12 10 1Ah 10h to 0s 1s only
4000h 4000h EPROM 5 12.5 01 1Ch 11h No 0s only
TMS370 C810 1F00h 0100h EEPROM 5 12 10 1Ah 10h to 0s 1s only
7000h 1000h EEPROM 5 12 10 1Ch 10h to 0s 1s only
TMS370 C850 1F00h 0100h EEPROM 5 12 10 1Ah 10h to 0s 1s only
7000h 1000h EEPROM 5 12 10 1Ch 10h to 0s 1s only
