Texas Instruments TMS370 User Manual
Page 24
Properly Installing the Programmer Hardware
1-10
Introduction and Installation
2) Connect port A of the XDS to the PC by using the cable supplied with the
XDS.
3) Ensure that the switches on the XDS Communications board are set as
in Table 1–1.
Table 1–1. XDS Memory Expansion/Communications Board Switch Settings
Switch No.
S1
S2
S3
S4
1
Off
Off
Off
Off
2
Off
On
Off
Off
3
Off
Off
Off
Off
4
Off
On
On
Off
5
On
Off
On
On
6
Off
Off
On
On
7
On
On
On
Off
