5. Percent display
6. Flow rate (When custom unit is selected)
7. Range display
In the range display, the range currently used is displayed (any one of the ranges 1 to 4). The screen
example above shows that Range 1 is currently used.
When multi-range is selected, the displayed range changes automatically as the range used is changed.
Numeric value Within the range of +125.0% to −125%,
displayed to the decimal place of 0.1%.
Unit
"%" fixed.
* If the value goes out of the display range, an error message appears.
Numeric value 7 digits maximum including a decimal point
are displayed. (Up to 9999999)
4 significant digits: The value is obtained by
multiplying m
3 /min by the set coefficient
Unit 7 digits maximum are displayed.
Flow direction In the case the flow is in reverse direction ,
“ ” is displayed.
In the case the flow is in forward direction,
not displayed.
Identification charanter “ ” is character to show the custom unit.
Numeric value The span of the range being used
Unit
7 digits maximum are displayed.
When custom unit is selected, identification
character “ ” is displayed.
Range The range being used is displayed as follows:
R1: Range 1
R2: Range 2
R3: Range 3
R4: Range 4
