91
Group Table
Configure SNMP v3 group table.
Security Name (User ID): Assign the user name that you have set up in user table.
Group Name: Set up the group name.
Click Add to add context name.
Click Remove to remove unwanted context name.
Access Table
Configure SNMP v3 access table.
Context Prefix: Set up the context name.
Group Name: Set up the group.
Security Level: Select the access level.
Context Match Rule: Select the context match rule.
Read View Name: Set up the read view.
Write View Name: Set up the write view.
Notify View Name: Set up the notify view.
Click Add to add context name.
Click Remove to remove unwanted context name.
MIBview Table
Configure MIB view table.
ViewName: Set up the name.
Sub-Oid Tree: Fill the Sub-OID.
Type: Select the type – exclude or included.
Click Add to add context name.
Click Remove to remove unwanted context name.
