Transition Networks SISGM1040-162D-LR
Technical Support: 1-800-260-1312 International: 00-1-952-941-7600
115
Install
DIN rail kit for DIN-type cabinet and wall mount ear for wall
mount install
Operation Temp. -10
o
C to 60
o
C (14
o
F to 140
o
F)
Operation
Humidity
5% to 95% (Non-condensing)
Storage
Temperature
-40 o C to 85 o C
Case Dimension IP-30, 72 mm (W) x 105 mm (D) x 152mm (H)
EMI
FCC Class A
CE EN61000-4-2 (ESD)
CE EN61000-4-3 (RS)
CE EN61000-4-4 (EFT)
CE EN61000-4-5 (Surge)
CE EN61000-4-6 (CS)
CE EN61000-4-8
CE EN61000-4-11
CE EN61000-4-12
CE EN61000-6-2
CE-EN61000-6-4
Safety UL, cUL, CE/EN60950-1
Stability testing
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
X-Ring
Supports X-Ring, Dual Homing, and Couple Ring
Provides redundant backup feature and recovery time from
failure less than 300ms
VLAN
Port based VLAN
IEEE802.1Q Tag VLAN (256 entries)/VLAN ID (up to 4 K,
VLAN ID can be assigned from 1 to 4096)
