Transition Networks SISGM1040-162D-LR
Technical Support: 1-800-260-1312 International: 00-1-952-941-7600
6
Off Power input 1 is inactive
Green Power input 2 is active
PWR2
Off Power input 2 is inactive
Red
Power input 1 or 2 is inactive or port link
failure (depends on Fault Relay Alarm
configuration) Fault
Off
Power input 1 and 2 are both active, or no
power inputs
Green SFP port is linking
Blinking Data is transmitting or receiving
LNK/ACT
(for P7, P8 SFP)
Off Not connected to network
Green
(upper LED)
Connected to network
Blinking
(upper LED)
Networking is active
Off
(lower LED)
No connected to network
Green
(lower LED)
The port is operating at speed of 1000M
P1 ~ P8 (RJ-45)
Off
(lower LED)
The port is disconnected or working at speed
of 10/100M
