Transition Networks SISGM1040-162D-LR
Technical Support: 1-800-260-1312 International: 00-1-952-941-7600
29
IEEE 802.1Q VLAN
vlan 8021q name
[GroupName]
vid
[VID]
V Change the name of
VLAN group, if the
group didn’t exist, this
command can’t be
applied.
switch(vlan)#vlan 8021q name
test vid 22
vlan 8021q port
[PortNumber]
access-link untag
[UntaggedVID]
V Assign a access link
for VLAN by port, if the
port belong to a trunk
group, this command
can’t be applied.
switch(vlan)#vlan 8021q port 3
access-link untag 33
vlan 8021q port
[PortNumber]
trunk-link tag
[TaggedVID List]
V Assign a trunk link for
VLAN by port, if the
port belong to a trunk
group, this command
can’t be applied.
switch(vlan)#vlan 8021q port 3
trunk-link tag 2,3,6,99
or
switch(vlan)#vlan 8021q port 3
trunk-link tag 3-20
vlan 8021q port
[PortNumber]
hybrid-link untag
[UntaggedVID]
tag
[TaggedVID List]
V Assign a hybrid link for
VLAN by port, if the
port belong to a trunk
group, this command
can’t be applied.
switch(vlan)#vlan 8021q port 3
hybrid-link untag 4 tag 3,6,8
or
switch(vlan)#vlan 8021q port 3
hybrid-link untag 5 tag 6-8
vlan 8021q trunk
[PortNumber]
access-link untag
[UntaggedVID]
V Assign a access link
for VLAN by trunk
group
switch(vlan)#vlan 8021q trunk 3
access-link untag 33
vlan 8021q trunk
[PortNumber]
trunk-link tag
[TaggedVID List]
V Assign a trunk link for
VLAN by trunk group
switch(vlan)#vlan 8021q trunk 3
trunk-link tag 2,3,6,99
or
switch(vlan)#vlan 8021q trunk 3
trunk-link tag 3-20
vlan 8021q trunk
[PortNumber]
hybrid-link untag
[UntaggedVID]
tag
V Assign a hybrid link for
VLAN by trunk group
switch(vlan)#vlan 8021q trunk 3
hybrid-link untag 4 tag 3,6,8
or
